Infrared Thermal Imaging Camera

Product Description

FLTG300 is a thermal Imaging Camera which combines the functions of surface temperture measurement and real-time thermal Imaging.

To improve recognition,this product is equipped with a vision camera.Based on pratical requirements,it can turn thermal image into visional image.Thermal image into visional image. Thermal Image and visional image can be stored them in PC which are used to generate report or for printing.FLTG300 is easy to operate.After seconds it can be tested. This product is the potimum product for elecrician and maintaineer. It can quickly find out the problem area.



The following functions help to improve the accuracy and usability of product:

1. Adjustable radiation coefficient and reflection background compensation help to improve the accurancy of the measurement of semi-reflective surface.

2. The marking of hot spot and cold spot can help user to locate the hottest and coldest area of thermal imaging temperature.

3. Options of color palette



Features

- For the harsh environment of the site application optimization design

- Engineering design, the test can withstand 2 meters (6.5 feet) of the drop

- Dust, waterproof, IP54 protection grade

- Provide quick and clear, sharp images that are needed to find the fault

- Excellent thermal sensitivity (NETD) can be found to be extremely subtle in temperature differences (it is likely to indicate failure)



Specification

Display	2.8 inch Color display
Resolution	60x60
Total pixels	3600
FOV/Shortest focal length	20°x20°/0.5m
Thermal sensitivity	0.15°C
Measuring mode	Infrared focal plane measuring temperature
Temperature range	-20°C~300°C(-4F°~572°F)
Measuring accuracy	2%/±2°C
Wavelength range	8~14μm
Image frequency	25Hz
Emissivity	0.1~1.0Adjustable
Focus Mode	Fixed
Palette	Iron color, rainbow, black and white
Image Storage	SD card(4G)
File Format	bmp
Set control	Unit Adjustment/Language/Date Time Format/automatic shutdown
Battery type	4*AA alkaline batteries
Adapter voltage	DC 5V output
Operating temperature	0°C~50°C
Storage temperature	-40°C~70°C
Humidity	<90%RH
Vibration	2G,IEC 60068-2-6
Drop resistance	2m
Dimension	230x80x52mm
Weight	410g
